| Model | Specification(mm) |
| Model Number | HD-013 |
| Brand Name | HaoDa |
| Single side | Can be customized according to requirements |
| Double side | |
| End Shelf | |
| Upright(mm) | |
| Layer Board(mm) | T:0.6~0.8 |
| Back Panel(mm) | T:0.5~0.8 |
| Bracket(mm) | T:1.8~3.0 |
| Color | As per client’s requirement |
| Surface | Electrostatic spray surface |
| Feature | Anti-rust, Corrosion-protection |
| Use Area | Supermarket |
| Structure | Knock down structure, easy assembling, convenient for delivery |
| Loading Capacity | Can be customized as required |
| Type | Multi-Level |
| Basic component | Size (cm) | ||
| Upright and leg |  |
Vertical section | 30*60/30*70/30*80/30*100 |
| height | 1000-3400 | ||
| thickness | ../2.0/2.5/.. | ||
| Leg depth | 300/350/400/450/500/550/600/650 | ||
| Shelf |  |
Length | 700/900/1000/1200 |
| width | 300/350/400/450/500/550/600/650 | ||
| thickness | 0.6/0.7/0.8/1.0 | ||
| Back panel |  |
Length | 700/900/1000/1200 |
| height | 190/290 | ||
| thickness | 0.5/0.6/0.7/0.8 | ||
| bracket |  |
Length | 300/350/400/450/500/550/600/650 |
| thickness | 2.5/3.0 | ||
| Top cover |  |
Length | 700/900/1000/1200 |
| width | 60/70/80/100 | ||
| thickness | 0.6/0.7/.. | ||
| Front board |  |
Length | 700/900/1000/1200 |
| thickness | 0.6/0.7/.. | ||
The above specifications are only a small part, our factory is a custom project, can customize different sizes and thicknesses.
A: Of course. We can, according to your requests, produce the satisfying product which you need.
A: Yes, our products are mainly made of metal but we also produce accessory shelves or displays with wood, titanium alloy, acrylic, glass, etc.
A: We have no requirements, but our prices are generally FOB prices, in short, you need to bear the sea freight, so my suggestion is a whole container or LCL, otherwise it is not cost-effective for you.
A: Yes, samples are available at any time. We charge some sample cost and will return it during the next order.
A: Our factory is located in changshu.Jiangsu. Close to Shanghai. You are warmly welcome to visit whenever you are available.
A: In general, within 15 days. It also depends on the order quantity and shelving design.
A: Payment terms: 30% of the deposit upon signing the PI, and the balance will be cleared by T/T before delivery.
A: Since different customers and projects have different requirements for product size and specifications, in general, we need to know the following information for a quick quote:
For Display Shelving
1)Tell me all the size and thickness requirements of the products you need, preferably with clear pictures.
2)It is better to tell us the quantity you require, and we will give you a discount according to the calculation.
3) I will give the price in RMB and US dollar, because the exchange rate is different, and the specific price is based on RMB.
4)It is best to make a list of the products you need, attached with your requirements and quantities.
5)Due to the fluctuating price of materials, when the price of materials rises too much or falls too much, the previous price may need to be recalculated. I am sorry for any inconvenience caused to you. (The duration of the quotation is usually one week)
If you are not sure about the above information, please let us know your storage or display needs, then our friendly and knowledgeable sales staff are happy to provide you with a professional shelf solution for your reference.
A: The difference between these two kinds of racks is upright. Main rack is the start rack with 2 uprights and add on rack is the continue rack with only 1 upright. For example, if there are 15 wall racks against the wall, the structure will be 1 main rack+ 14 add on racks.
A: Generally, shelves are flat packed by air bubble film/ film in standard export cartons. Other packings like wooden boxes are available to clients’ requirements.
